CEM3708T
Model Number:
CEM3708T
Brand:
ABB
Frame:
215TC
CEM3708T Product Information Packet
Enclosure: TEFC
Frequency: 60 Hz
Output: 5 HP
Speed: 1165 RPM
Phase: 3
Voltage: 460 V/230 V
Current: 15.6 A @ 208 V
Ambient Temp: 40 C
Efficiency: 89.5%
Motor Type: 3752M
Mount Arrangement: F1
Length: 21.26 IN
Shaft Diameter: 1.375 IN
Pulley Face Code: C-Face
Load Characteristics
| Rated Load | 0% | 25% | 50% | 75% | 100% | 125% | 150% | S.F. |
| Power Factor | 5 | 33 | 52 | 64 | 70 | 74 | 76 | 72 |
| Efficiency | 0 | 84.4 | 89.3 | 90.2 | 89.7 | 88.6 | 87.1 | 89.0 |
| Speed (RPM) | 1198 | 1192 | 1183 | 1175 | 1165 | 1154 | 1141 | 1158 |
| Line Amps | 3.98 | 4.28 | 5.07 | 6.08 | 7.39 | 8.87 | 10.60 | 8.28 |
Features
- General purpose motor for use in wide range of applications
- Single speed code
- NEMA Premium efficiency with 3-year warranty
- Cast iron frame
$1,524.97 /each
Select Quantity:
Standard Repair Lead Time: 1 Week
Warranty: 1 Year from Date of Shipment
Servo Motor Send-In Repair Process:
Fill Out Repair/Shipping Document
Ship Your Item To A&C Electric
A&C Electric Certified Technicians Dismantle Your Product
A&C Electric Sends you a Quote for Approval of Repair
Motor is rebuilt and shipped back to you ASAP
